Draw2Fab: Professional HVAC Layout, Estimation, and Compliance Suite

Streamline Your HVAC Takeoffs, Duct Design, and Municipal Permitting

Draw2Fab is a purpose-built WordPress plugin designed for mechanical contractors, sheet metal fabricators, and HVAC professionals. By combining digital floor plan tracing, automated heat loss/gain calculations, instant duct sizing, and automated municipal ventilation checklists, Draw2Fab replaces multiple standalone software subscriptions with a single, powerful workspace right inside your WordPress site.

Core Features and Capabilities

• Digital Plan Tracing & Quick Load: Trace floor plans and automatically calculate block loads, room-by-room CFM requirements, and window/door heat loss factors.
• Automated Duct Routing & BOM: Draw runs, place plenums, and instantly generate an accurate Bill of Materials (BOM) complete with fittings, joints, hangers, and insulation wrap quantities.
• Code-Compliant Municipal Checklists: Automate complex local requirements like BC Building Code Section 9.32 ventilation schedules and TECA checklists (Checklist 1 and Checklist 2) with built-in validation.
• Integrated Job & Inventory Management: Track job progress, manage stock levels, print professional reports, and sync directly with your shop’s inventory system.

Professional Pricing Options

Choose the model that fits your business volume, whether you prefer outsourcing your takeoffs or running the app suite yourself.

Plan Level	Pricing	What Is Included	Best For
First Project Free	$0.00	Your first complete house layout, HVAC takeoff package, and municipal checklist processed at no charge.	Contractors wanting to test the speed and accuracy risk-free.
Pay-Per-Use (PPU) Takeoff	$199 per project	A complete, turn-key HVAC takeoff package, duct sizing schedule, and permit checklist delivered ready for your review.	Busy contractors who want expert takeoffs without running software in-house.
Pro Contractor SaaS	$499 per month	Full, unlimited access to the Draw2Fab web app suite, automatic updates, BOM generators, and inventory tracking tools.	Shops and active installers wanting full control over unlimited jobs.

Why Choose Draw2Fab?

• Eliminate Permit Rejections: Built-in validation rules flag unverified duct lengths, low-mounted exhaust grilles, and balancing discrepancies before you submit to the municipality.
• Save Hours of Administrative Work: Turn a raw architectural PDF into a fully sized, estimated, and documented mechanical package in minutes instead of days.
• No External Software Lock-In: Operates natively on a desktop or a mobile device, with nothing to download, and includes daily backups, keeping you in complete control of your data, fittings library, and client records.

Ready to transform your HVAC workflow? Submit your first project plan today to claim your free introductory layout package. Contact me now.
